Hyundai Serene Plus Series – 1 Ton (HAC-14H-T5)

Highlights

• 1 Ton Inverter Air Conditioner
• Cooling & Heating Function
• Fast & Strong Cooling Performance
• Built-in WiFi Connectivity
• Energy Efficient Inverter Technology
• Bigger Outdoor Unit
• Air Purify Filter
• Filter Cleaning Reminder
• Sleep Mode Function
• Low Voltage Operation (165–265V)
• Eco-Friendly R410A Refrigerant
• IPX4 Outdoor Unit Protection
• Low Noise Operation
• Suitable for Bedrooms & Small Offices

Technical Description

The Hyundai Serene Plus HAC-14H-T5 is a 1 Ton inverter air conditioner designed to provide efficient cooling and heating with advanced smart features. With a cooling capacity of 12500 BTU/h and heating capacity of 12500 BTU/h, it delivers reliable year-round comfort with optimized energy usage.

Equipped with WiFi connectivity, sleep mode, air purification filter, and filter cleaning reminder, this model ensures convenient operation and healthier airflow. Its wide voltage range of 165–265V provides stable performance even during voltage fluctuations, making it ideal for residential and office environments.

Technical Specifications

• Model: HAC-14H-T5
• Capacity: 1 Ton

Cooling

• Capacity: 12500 BTU/h (3400–14300)
• Power Consumption: 3663W (1020–4200)
• Current: 4.3A (1.2–7.2)

Heating

• Capacity: 12500 BTU/h (3400–14300)
• Power Consumption: 3696W (1020–4400)
• Current: 4.3A (1.2–6.8)

Electrical Details

• Rated Current (IEC/EN60335):
  • Cooling: 7.2A
  • Heating: 6.8A
• Power Input Cooling: 1000W (300–1650)
• Power Input Heating: 973W (300–1600)
• Rated Power Input (IEC/EN60335):
  • Cooling: 1650W
  • Heating: 1600W

Airflow & Pressure

• Indoor Air Volume:
  • Cooling: 580 m³/h
  • Heating: 620 m³/h
• Max Pressure Discharge: 4.5MPa
• Max Pressure Suction: 1.9MPa

Noise Level

• Indoor Noise: 44dB(A)
• Outdoor Noise: 53dB(A)

Weight

• Indoor Unit Weight: 9.5kg
• Outdoor Unit Weight: 27kg

General Specifications

• Rated Voltage: 220–240V~
• Lowest Working Voltage: 165–265V~
• Rated Frequency: 50Hz
• Refrigerant/Charge: R410A / 0.980kg
• Outdoor Unit Waterproof Protection: IPX4
